The 48 Volt 27 HP AC drive train is powerful enough to go over the toughest terrain without all the noise of a gas-powered engine. Nitrogen-Assisted Independent Suspension and Four-Wheel Hydraulic Brakes will keep you in full control. Built for stability and performance.
*Range estimates assume a fully charged battery pack.
Highlights
- Run Time On A Single Charge – Over 45 Miles*
- Maintenance Free Discover™ Dry Cell Battery
- 48 Volt, 27 Hp With Over 220 Ft. Lbs. Of Torque
Motor
- Engine Type: AC Induction
- Battery Voltage: 48
- Battery Type: Discover™ Dry Cell
- Battery Capacity: 2080 Amp/Hours
- Charge Time: 6 – 10 hours
- Charging System: 1,200 Watt / On-Board Charger
- Horsepower: 27
- Torque (ft. lbs.): 220
Drive Train
- Transmission: L/M/H/N/R
- Drive System: 2WD / 4WD
- Locking Differential: Front
- Final Drive: Direct
- Range: > 42 Miles*
Chassis / Suspension / Brakes
- Front Suspension: Dual A-Arm
- Rear Suspension: Dual A-Arm
- Shocks: Hydraulic W/ Nitrogen Assist
- Front / Rear Brakes: Hydraulic Disc
- Parking Brake: Mechanical
- Front Tires: 26 x 9-14
- Rear Tires: 26 x 11-14
- Wheels: Aluminum
Dimensions
- Overall Vehicle (L x W x H): 110″ x 62″ x 73″
- Wheel Base: 72.5″
- Cargo Bed Dimensions (L x W x H): 30″ x 41″ x 11″
- Cargo Bed Dump Type: Gas Assist
- Cargo Bed Capacity: 500 LBS
- Person Capacity: 2
- Empty Vehicle Weight Rating: 2,061 LBS
- Gross Vehicle Weight Rating: 2,764 LBS
- Tow Rating: 1,500 LBS
- Ground Clearance: 11″
Other
- Instrumentation: Analog Speedometer & Tachometer With LCD Rider Information
- Winch: 3,500 LBS
- Roof: Yes
- Windshield: 2-Piece
- Brake Lights: Yes
- Headlights: High / Low Beam
- Turn Signals & Horn: Yes
- Doors: Not Available
- Electronic Power Steering: Not Available
- Warranty: 2-Year Limited
- Colors: Cavalry Blue, HISUN Red, Black Ops, Destroyer Grey
