Surron Light Bee X
The Electric Light Bee SUR-RON X packs a ton of fun for all terrain riding. 60V and more than 6kW of peak power from a removable Panasonic Lithium ion battery pack. Forged light weight alloy frame combined with hi-spec components. 4 Piston Hydraulic Disc Brakes Front and Rear. LCD dash with USB charger point.
Powerful yet nimble and with a climbing ability of over 45°, it offers hours of near silent fun with a range of 20 to 60 miles per charge (depending on Eco or Sport Mode). Top speed 45 mph, and usually charges in about 3 hours with a powerful 10A charger.
Available In-Store: Get it today.
Call dibs today
We'll hold your purchase and arrange pickup with you during our normal business hours.
Buying online has never been easier
Fast, convenient, wicked easy.
The Electric Surron Light Bee X packs a ton of fun for all terrain riding. 60V and more than 6kW of peak power from a removable Panasonic Lithium ion battery pack. Forged light weight alloy frame combined with hi-spec components. 4 Piston Hydraulic Disc Brakes Front and Rear. LCD dash with USB charger point.
Powerful yet nimble and with a climbing ability of over 45°, it offers hours of near silent fun with a range of 20 to 60 miles per charge (depending on Eco or Sport Mode). Top speed 45 mph, and usually charges in about 3 hours with a powerful 10A charger.
| MOTOR | |
| Motor Type: | PMSM |
| Mounting Position: | Mid |
| Weight / Motor External Diameter: | 15 lbs. (7.0kg) / 7.09″ (180mm) |
| Motor Axial Length: | 5.12″ (130mm) |
| Peak Efficiency: | 95.60% |
| Cooling Method: | Air-Cooled |
| CONTROLLER | |
| Controller Type: | X Version Sine Wave |
| Dimensions: | 9.45″ x 4.33″ x 1.97″ (240mm x 110mm x 50mm) |
| Peak Efficiency: | 98.50% |
| Power Modes: | Eco and Sport |
| MOTOR POWER SYSTEM | |
| Rated Voltage: | 60V (DC) |
| Rated Power / Peak Power: | 3000W / 6000W |
| Rated Torque / Peak Torque: | 10.2Nm / 39.00Nm |
| Motor Shaft Output Torque @ 1000RPM: | 35.40Nm |
| Rated Rotation Speed: | 4300rpm |
| Peak Efficiency: | 97.8% |
| Range of Efficiency (≥80): | 1.4Nm – 21.5Nm |
| TRANSMISSION | |
| Gear Ratio: | 1:7.6 |
| Transmission: | Primary Belt & 420 Drive Chain |
| Belt Brand & Model: | German Continental Brand, 8M CXA |
| ELECTRICAL COMPONENTS | |
| Horn: | European Standard Horn |
| Battery: | 60V 32A Lithium Battery with 176 Panasonic Cells |
| Battery Life Time: | 500 Cycles (and then the capacity reduces step by step) |
| Battery Charge Level: | Integrated Battery LCD Display |
| Charger: | 10A |
| Charging Time: | 2.5-3.5 Hours |
| USB Connection: | USB-2.1 A Single Socket |
| Speedometer: | LCD Digital Speedometer |
| LED Headlight & Rear Light: | Yes |
| FRAME DETAILS | |
| Chassis – Swing Arm Material: | No. 6061 T4 & T6 Aluminum Alloy |
| Chassis Construction Method: | Forged by 6000 Tons of Pressure |
| Chassis Surface & Color Processing: | Anodic Oxidation |
| Front Suspension: | Inverted Suspension Fork with 8″ Travel |
| Rear Shock Absorber: | DNM TR Suspension Link System |
| Wheel Type & Size: | Spoke Wheels, Front/Rear 19 x 1.4 Alloy Hubs |
| Tire Size: | Front/Rear 70/100-19 CST |
| Top Speed: | 47 MPH / 73KMH (Varies depending upon load and gearing) |
| Net Weight: | 103 lbs. (47kg) plus battery |
| Max Load: | 220 lbs. (100kg) |
| Max Climb: | 45° |
| Rear Sprocket: | 48T |
| Side Stand: | Yes with kill switch |
| Vehicle Dimensions: | 73.62″ x 30.71″ x 40.94″ (1870mm x 780mm x 1040mm) |
| Min. Ground Clearance: | 10.63″ (270mm) |
| Wheelbase: | 49.61″ (1260mm) |
| Seat Height: | 33.07 to 34.65″ (84 to 88cm) |
