Pricing
- Warranty (Months): 6
Engine
- Engine Type: Single-Cylinder
- Cylinders: 1
- Cooling: Air
- Bore: 52.4 mm; 2.06 in
- Stroke: 51.8 mm; 2.04 in
- Displacement: 112 cc; 6.8 ci
- Compression Ratio: 9.2:1
- Starter: Electric / Kick
- Fuel Type: Gas
- Emissions Standards: Standard Emissions
- Carburetion Type: Fuel Injected
Transmission
- Transmission Type: Continuously Variable (CVT)
- Reverse: Yes
Drive Line
- Driveline Type: 4X2
Technical Specifications
- Length: 58.5 in; 1485.9 mm
- Width: 40.2 in; 1021.1 mm
- Height: 39 in; 990.6 mm
- Wheelbase: 40.6 in; 1031.2 mm
- Wet Weight: 287.5 lbs; 130.4 kg
- Fuel Capacity: 1.8 gal; 6.8 l
Exterior
- Frame: Steel
Suspension
- Front Suspension Type: A-Arm
- Front Travel: 5 in; 127 mm
- Rear Suspension Type: Swing Arm
- Rear Travel: 5.7 in; 144.8 mm
Wheels & Tires
- Front Tire (Full Spec): Duro AT 18 X 7-8
- Rear Tire (Full Spec): Duro AT 18 X 9-8
Brakes
- Front Brake Type: Dual Sealed Drum
- Rear Brake Type: Drum
Seats
- Seat Height: 29.5 in; 749.3 mm
- Number Of Seats: 1
Instrumentation
- Speedometer: Not Available
- Trip Odometer: Not Available
Storage
- Glove Box / Dash Storage: Not Available
Lights
- Type: Halogen
Glass
- Rearview Mirrors: Not Available
- Windshield: Not Available
