Pricing
- Warranty (Months): 6
Engine
- Engine Type: Single-Cylinder
- Cylinders: 1
- Cooling: Air
- Bore: 39 mm; 1.54 in
- Stroke: 41.4 mm; 1.63 in
- Displacement: 49 cc; 3 ci
- Compression Ratio: 8.5:1
- Starter: Electric / Kick
- Fuel Type: Gas
- Emissions Standards: Standard Emissions
- Carburetion Type: Carburetor
Transmission
- Transmission Type: Continuously Variable (CVT)
- Reverse: No
Drive Line
- Driveline Type: 4X2
Technical Specifications
- Length: 49.2 in; 1249.7 mm
- Width: 32.3 in; 820.4 mm
- Height: 30.3 in; 769.6 mm
- Wheelbase: 32.7 in; 830.6 mm
- Ground Clearance: 3.5 in; 88.9 mm
- Wet Weight: 220 lbs; 99.8 kg
- Fuel Capacity: 1.5 gal; 5.7 l
Exterior
- Frame: Steel
Suspension
- Front Suspension Type: A-Arm
- Front Travel: 2.4 in; 61 mm
- Rear Suspension Type: Swing Arm
- Rear Travel: 2 in; 50.8 mm
Wheels & Tires
- Front Tire (Full Spec): Duro® AT 16 X 6.5-7
- Rear Tire (Full Spec): Duro® AT 16 X 7-7
Brakes
- Front Brake Type: Dual Sealed Drum
- Rear Brake Type: Sealed Drum
Seats
- Seat Height: 23 in; 584.2 mm
- Number Of Seats: 1
Instrumentation
- Speedometer: Not Available
- Tachometer: Optional
- Trip Odometer: Not Available
Storage
- Glove Box / Dash Storage: Not Available
Lights
- Type: Halogen
Glass
- Rearview Mirrors: Not Available
- Windshield: Not Available
